Isiguquli seMpompo yeSola

Ukunika amandla iinkqubo zakho zamanzi ngokuzinzileyo kunye ne-CDADA Solar Pump Inverter-isisombululo esihlakaniphile, esingekho kwigridi esenzelwe ngokukodwa izicelo zokumpompa amanzi ngelanga kwezolimo, imfuyo, ukunkcenkceshela, kunye nokunikezelwa kwamanzi okude.

Ngokungafaniyo nabaguquleli be-PV abaqhelekileyo, le CDADA ye-Solar Pump Inverter idibanisa i-MPPT ephezulu (i-Maximum Power Point Tracking) ngokuthe ngqo kunye ne-3-phase ye-AC motor drive, eyenza ukuguqulwa okuthe ngqo kwamandla e-solar DC kwi-variable-frequency AC ukuqhuba iipompo ezingaphantsi kwamanzi, ezingaphezulu, okanye ze-centrifugal-ngaphandle kokufuna iibhetri okanye uxhulumaniso lwegridi.

Ifumaneka kwiireyithingi zamandla eziquka i-15kW (kwaye i-scalable ukusuka kwi-1.5kW ukuya kwi-30kW +), ixhasa ii-motor induction induction yesigaba esi-3 kwaye ibonakalisa i-V / F eguquguqukayo kunye nolawulo lwe-vector ukuqala kakuhle, ukusetyenziswa kwamandla, kunye nokusebenza okuzinzile phantsi kokukhanya kwelanga okuguquguqukayo. Ukukhuselwa okwakhelwe ngaphakathi-kubandakanya ukubonwa kwe-dry-run, ngaphezulu / ngaphantsi kwe-voltage, i-overcurrent, i-short-circuit, kunye nokukhusela i-motor stall-ukuqinisekisa ukuthembeka kwexesha elide kwiindawo ezisemaphandleni ezinzima.

Ngokuzikhethela kwe-IP65 evaliweyo, unxibelelwano lwe-RS485 / i-Modbus, kunye nenkxaso yokubeka iliso kwiselula, i-inverter ye-CDADA ihambisa ukuzimela, ukufikelela kwamanzi okugcinwa kwamanzi aphantsi anikwe amandla ahlambulukileyo ngenxa yelanga-akulungele iifama, iidolophana, amaqula asentlango, kunye neendawo zokuhlala.

Iimpawu eziphambili kunye neeNgcaciso

Uphawu: CDADA | Umenzi: Shanghai DADA Electric CO.,LTD

Uhlobo lweMveliso: I-Solar Water Pump Inverter (I-Off-Grid, Ibhetri-Free)

Uluhlu lwamandla: 1.5kW - 30kW+ (umzekelo, i-15kW imodeli yesigaba se-3)

Igalelo: DC ukusuka kuluhlu lwePV (uluhlu lwamandla ombane lweMPPT: umz., 200–800V DC)

Imveliso: Isigaba esi-3 se-AC (0–480V, 0–50/60Hz) yeenjini zempompo eziqhelekileyo

Indlela yokulawula: V/F + Ulawulo lweVector engenazinzwa

Ubuchule beMPPT: > 99% - yandisa isivuno nangaphantsi kwe-shading partial

Indlela yokuQalisa: Isiqalo esithambileyo / Ukukhanya kwelanga ngokuzenzekelayo - akukho ngenelelo ngesandla

Ukhuseleko oluphambili:

Ukomisa-ukubaleka / Ukungabonwa kwamanzi

Ngaphezulu/Ngaphantsi kombane wePV

I-Overcurrent & short-circuit

Ukugqithiswa kweMotor kunye nelahleko yesigaba

Ukutshisa ngokugqithisileyo

Unxibelelwano: I-RS485, i-Modbus RTU (ukhetho lwe-Wi-Fi/GPRS yokubeka iliso kude)

Indawo ebiyelweyo: IP20 (yangaphakathi) okanye i-IP65 (ireyithingi yangaphandle, uyazikhethela)

Ubushushu bokusebenza: -25°C ukuya +60°C (ukwehla ngaphezu kwe-50°C)

Izicelo: Unkcenkceshelo lwezolimo, ukunkcenkceshela imfuyo, ubonelelo lwamanzi ezilalini, iinkqubo zemithombo, ukubuyiselwa kwentlango.

Kutheni ukhetha i-CDADA Solar Pump Inverter?

★ Ukusebenza okuNyaniso ngaphandle kweGridi

Akukho gridi okanye iibhetri ezifunekayo-ziqhuba ngokuthe ngqo kwiipaneli zelanga, ukunciphisa iindleko zenkqubo kunye nobunzima.

★ Intelligent Dry-Run Protection

Ukumisa impompo ngokuzenzekelayo xa amanzi ephantsi-ithintela ukutshiswa kwemoto kwaye yandisa ubomi besixhobo.

★ Ubuchule obuphezulu beMPPT + Ulawulo lweMoto

Ukulungiswa kwe-double-core optimization kuqinisekisa umthamo omkhulu wamanzi ngewathi nganye yokukhanya kwelanga.

★ Rugged for Use Rural

Igalelo lamandla ombane abanzi, ukunyamezela ubushushu obuphezulu, kunye nomlinganiselo okhethiweyo we-IP65 kwindawo enothuli/efumileyo.

★ Ufakelo olulula kunye noLondolozo

Uyilo lweplagi kunye nempompo ngokuziqalela ngokutsha ekuphumeni kwelanga-ilungele iisayithi ezikude, ezingahoywanga.

★ Inkxaso yeHlabathi kunye neNdleko yeNdleko

Ixhaswa liqela leR&D le-Shanghai DADA, elinamaxabiso akhuphisanayo neempawu zaseYurophu.

Usetyenziso oluqhelekileyo

★ Ukunkcenkceshela ngezoLimo: Izidiliya, amasimi erayisi, iifama zemifuno

★ Ukunkcenkceshelwa kwemfuyo: Iifama zeenkomo ezikude, iifama zebhokhwe

★ Ukufakwa koMbane emaphandleni: Iinkqubo zamanzi okusela ezilalini eAfrika/eAsia/LATAM

★ Eco-Tourism: Iindawo ekuchithelwa kuzo iiholide ezingaphandle kwegrid ezinemithombo okanye amachibi asebenza ngelanga

★ Uncedo lweNtlekele: Ukuhanjiswa kwamanzi ngokukhawuleza emva kweempuphuma okanye iinyikima

Imibuzo ebuzwa qho

I-Q1: Ngaba ifuna ibhetri okanye uxhumano lwegridi?

I-A1: Hayi. I-CDADA Solar Pump Inverters isebenza nge-100% off-grid, ukudweba amandla ngokuthe ngqo kwiipaneli zelanga. Ziqala ukuphuma kwelanga zize zime ekutshoneni kwelanga—akufuneki mthombo wamandla wangaphandle ofunekayo.

Q2: Ngaba inokusebenza ngeentsuku ezinamafu?

A2: Ewe-ngemveliso encitshisiweyo. I-algorithm yeMPPT ngokuqhubekayo ilungelelanisa ukukhupha amandla amaninzi akhoyo, naphantsi kweemeko zokukhanya okuphantsi. Isantya sempompo siyacotha kodwa siyaqhubeka nokuzisa amanzi.

I-Q3: Isebenza njani i-dry-run yokukhusela?

I-A3: I-inverter ihlola umthwalo wemoto okanye utyikityo lwangoku. Ukuba ibona umthwalo ophantsi ongaqhelekanga (ebonisa ukuba akukho manzi), ivala impompo kwaye iphinde izame emva kwexesha elimiselweyo-ukuthintela umonakalo.

I-Q4: Ngaba ndingayisebenzisa ngempompo ye-AC ekhoyo?

I-A4: Ewe-ngokude nje ipompo i-3-phase induction type kwaye ihambelana ne-voltage ye-inverter kunye nokulinganisa amandla (umzekelo, i-15kW inverter → ≤15kW pump). Iimpompo zesigaba esisodwa zifuna imodeli eyahlukileyo.

I-Q5: Kutheni ukhetha i-CDADA ngaphezu kwezinye iimpawu zempompo yelanga?

A5: CDADA inikeza:

● IMPPT + VFD edityanisiweyo kwiyunithi enye (akukho balawuli bongezelelweyo)

● Ukuthembeka okungqiniweyo kumazwe angama-50

● Iinketho zonxibelelwano olululo (iModbus, IoT)

● Inkxaso yobuchwephesha basekuhlaleni & iinxalenye ezikhawulezayo ezisecaleni

● Elona xabiso liphezulu kusetyenziso lwamandla aphakathi ukuya kuphezulu (5–30kW).
